Vertical Platform Lifts
Lehner Liftboy 1 / 2 / 3
Liftboy 1 / 2 / 3
A low-rise lifting platform for indoor or outdoor access, available in three versions with lifting heights from 595 to 970 mm.
At a glance
- Lifting height / Load capacity
- Liftboy 1: 595 mm / 180 kg; Liftboy 2: 830 mm / 300 kg; Liftboy 3: 970 mm / 240 kg
- Lifting speed
- 10 mm/s
- Surface treatment
- Powder coated in RAL 7035
- Optional finish
- Any RAL colour; stainless steel
Product information
Overview
Liftboy 1, 2 and 3 are low-rise vertical lifting platforms for overcoming small changes in level. The three versions provide lifting heights of 595 mm, 830 mm and 970 mm, with load capacities matched to each model.
The lift can be used indoors or outdoors and does not require floor mounting in its standard arrangement. Its comparatively low weight also allows it to be moved between suitable locations when configured for transport.
Access direction, platform controls, ramps, an upper landing door and other options can be selected for the assessed site. The final model, capacity, access arrangement and installation details must be confirmed before quotation or use.
Designed around everyday use
Key features
-
Three lifting heights
Choose a 595 mm, 830 mm or 970 mm lifting height to match the assessed change in level.
-
No standard floor fixing
The platform is designed to stand without floor mounting in its standard arrangement.
-
Indoor or outdoor use
The manufacturer specifies the Liftboy 1, 2 and 3 for both indoor and outdoor applications.
-
Configurable access
Side access, an upper side exit, ramps, control columns and an upper landing door are available as options.
-
Transportable option
Transport wheels and the low machine weight can support movement between suitable locations.
Technical details
Specifications
- Lifting height / Load capacity
- Liftboy 1: 595 mm / 180 kg; Liftboy 2: 830 mm / 300 kg; Liftboy 3: 970 mm / 240 kg
- Lifting speed
- 10 mm/s
- Surface treatment
- Powder coated in RAL 7035
- Optional finish
- Any RAL colour; stainless steel
- Net weight
- Liftboy 1: 53 kg; Liftboy 2 and 3: 95 kg
- Power supply
- 1 x 230 V / 50-60 Hz
- Total width
- Liftboy 1: 810 mm; Liftboy 2 and 3: 924 mm
- Total length
- Liftboy 1: 1180 mm; Liftboy 2 and 3: 1505 mm
- Options
- Side entry at lower level; side exit at upper level; control pillar
- Options
- Radio remote controls; transport wheels; door at upper landing
- Options
- Automatic door opener; contact bars for pit mounting
- Options
- Pillars for remote controls; manual ramp; extended ramp
See it in context
Product video
Watch the supplied product video without leaving this page.
Product documents
Downloads
Product questions
Frequently asked questions
Which Liftboy model covers the greatest height?
Liftboy 3 provides the greatest listed lifting height at 970 mm. Liftboy 1 is rated for 595 mm and Liftboy 2 for 830 mm.
Can Liftboy 1, 2 or 3 be used outdoors?
Yes. The manufacturer specifies indoor and outdoor use. The final finish, controls and site arrangement should be confirmed for the location.
Does the platform need to be fixed to the floor?
The manufacturer states that standard floor mounting is not required. Any pit, landing-door or site-specific arrangement must still be assessed and installed correctly.
Can the access direction be changed?
Several access options are available, including side access at the lower stop and a side exit at the upper stop. Confirm the required route during the site assessment.
Discuss the next step
Ask the team about Liftboy 1 / 2 / 3.
Share the staircase or level change involved and who will use the solution.
